Ingersoll Rand M200-M250 Screw Compressor
Description
- High-efficiency motors: 380V/3ph/50Hz, 6kV/3ph/50Hz, 10kV/3ph/50Hz, IP23 protection
- Two-stage compression for reliable and efficient compressor operation
- Maintenance-free direct drive system
- Optional air- and water-cooled aftercoolers with water separators
- Intelligent KT controller:
- Bilingual interface (Chinese/English)
- 15 event records
- Load/unload management with automatic start/stop function
- Automatic control of up to 8 compressors with the KT controller to meet non-standard requirements
- Modbus RTU communication protocol, RS485 serial communication port
- 304 stainless steel chiller (water-cooled)
- Low noise level: 85 dB(A) air-cooled / 82 dB(A) water-cooled
- Unit dimensions (mm): Low-voltage air-cooled: 4000 L x 1930 W x 2146 H; Water-cooled: 3684 L x 1990 W x 2054 H;
High-voltage air-cooled: 4650 L x 1930 W x 2146 H; Water-cooled: 4054 L x 1990 W x 2054 H;
- Unit weight (kg): M200 380 V: 5860 (air-cooled); 5132 (water-cooled);
6 kW: 6660 (air-cooled); 6227 (water-cooled);
10 kW: 7160 (air-cooled); 6527 (water-cooled);
M250 380V: 6030 (air-cooled); 5182 (water-cooled);
6 kW: 6740 (air-cooled); 6327 (water-cooled);
10 kW: 7280 (air-cooled); 6677 (water-cooled);
RM185 - RM315 Ingersoll Rand Screw Compressor
Description
- High-efficiency 400V/3-phase/50Hz/IP55/IE3 motor
- High-efficiency 6kW and 10kW/3-phase/50Hz IP23/GB2 motors
- Next-generation screw-drive rotor profile delivering industry-leading energy efficiency
- Maintenance-free direct drive system with gearbox
- IP54 control cabinet protection rating
- Standard air/water separator
- Luminance Series Controllers:
- Integrated IoT functionality for intelligent connectivity
- High-resolution 10.1-inch touchscreen display
- Fully isolated design with enhanced noise immunity, adaptable to various environmental conditions
- Modbus RTU communication protocol, RS485 serial communication port
- Low-noise enclosure: water-cooled 78 dB(A) / air-cooled 79-80 dB(A)
- Long-life spare parts (air filter 2,000 hours, oil filter 2,000 hours, oil separator 4,000 hours)
- Designed for high temperatures up to 46℃
- Dimensions (mm): 3800 L x 2150 W x 2320 H (suitable for low and medium pressure)
- Weight (kg): RM200i air-cooled 6220; RM200i water-cooled 5800; (suitable for low and medium pressure)
RM250i air-cooled 6265; RM250i water-cooled 5845; (suitable for low and medium pressure)
Ingersoll Rand RM90 Oil-Cooled Rotary Screw Air Compressors
Description
- High-efficiency 380-415 V / 3-phase / 50 Hz TEFC/IP55/IE3 motor
- Newly designed high-efficiency compressor unit
- Maintenance-free integrated direct-drive system with gearbox
- V-Shield™ Technology
- Integrated low-power cooling fan
- Factory-filled with Ultra-Joyne coolant, providing up to 8,000 hours of operation
- Fully welded IP54 metal control cabinet
- Le-180 Controller with IP54-rated control panel:
- Dual-language display (Chinese/English) with a user-friendly interface
- Web-based diagnostics and remote control
- Logging of over 300 events
- Modbus RTU communication protocol, RS485 serial port
- Standard IoT functionality
- Unit dimensions (mm): 90–110 kW: 2455 L x 1586 W x 1670 H
132–160 kW (Water-Cooled):
RS200 - RS355 Ingersoll Rand Screw Compressor
Description
- High-efficiency IE3 motor, 400V/3-phase/50Hz, IP23 protection rating
- High-efficiency 6kV/3-phase/50Hz and 10kV/3-phase/50Hz motors, IP23 protection rating
- Next-generation screw-type rotor profile delivers industry-leading energy efficiency
- Integration of advanced technologies such as V-Shield, PAC, and a suspended cooling system
- Maintenance-free direct gear drive system
- Choice of air-cooled and water-cooled chillers equipped with air-water separators
- IP54 electrical protection rating
- Luminance controller, IP54 control panel:
- User-friendly interface with Chinese and English display
- Online network diagnostics and remote control
- History logging of over 300 events
- Modbus communication protocol RTU, RS485 serial port
- Built-in IoT (Internet of Things) functionality as standard
- Low-noise enclosure, 75 dB(A)
- Designed for operation at temperatures up to 46°C and long-life spare parts (air filter life: 4,000 hours, oil filter: 4,000 hours, oil separator: 8,000 hours)
- Unit dimensions (mm): Low pressure: 3752 L x 2150 W x 2504 H; High pressure: 4577 L x 2150 W x 2504 H;
- Unit weight (kg): RS200 (low pressure): Air-cooled 6205; Water-cooled 6095; RS250 (low pressure): Air-cooled 6380; Water-cooled 6270;
RS200 (high pressure): air-cooled 8314; water-cooled 8204; RS250 (high pressure): air-cooled 8314; water-cooled 8204;
- Unit weight (kg): low pressure: RS315 air-cooled 8300; water-cooled 6842; RS355 air-cooled 8300; water-cooled 6882;
6 kW: RS315 air-cooled 9700; water-cooled 6712; RS355 air-cooled 9700; water-cooled 6552;
10 kW: RS315 air-cooled 9700; water-cooled
Description
- High-efficiency 380-415V/3-phase/50Hz motor, TEFC/IP55, IE3
- New design of robust and reliable Ingersoll Rand unit
- Maintenance-free integrated gear drive system
- Active Adaptive Control™ (PAC™) protection system
- V-Shield™ technology
- Highly efficient aftercooling system
- NEMA 4/IP65 control panel protection rating
- All-welded metal control cabinet with IP54 protection
- Intelligent Xe Series controller:
- Built-in auto-control function, ability to simultaneously control up to 4 air compressors with Xe Series controllers
- Modbus RTU communication protocol, RS485 serial interface
- Online network diagnostics and remote control
- 200 latest event logs
- Low-noise enclosure: 76 dB(A) for air-cooled / 72 dB(A) for water-cooled
- Unit dimensions (mm): RS132/160: 2855 L x 1899 W x 2107 H
- Unit weight (kg): RS132: air-cooled 3720; water-cooled 3780;
RS160: air-cooled 3820; water-cooled 3880;
Unit weight (kg): RS90ie air-cooled 3270; water-cooled 3478; RS132ie air-cooled 3646; water-cooled 3854;
RS110ie air-cooled 3364; water-cooled 3572; RS160ie air-cooled 4194; water-cooled 3986;
Air flow Maximum pressure Cooling type Voltage Price
Description
- All-new helical rotor profile with high-efficiency IE3 motor delivers industry-leading energy efficiency (16% improvement over previous models)
- Integrated advanced technologies including V-Shield™, PAC™, suspended cooling system, and direct-drive gearbox
- Standard moisture separator
- Highly intelligent Xe Series controller
- Xe-90 controller
- Built-in self-linking control function supporting up to 4 compressors equipped with Xe Series controllers
- Modbus RTU communication protocol, RS485 serial port
- Models with integrated refrigerated dehumidifier (operates in ambient temperatures up to 46°C, ensuring treated air quality in accordance with 1-4-1 standards)
- Long-life spare parts
- Standard ENL no-loss solenoid drain valve
- IP65 protection rating for control panel
- IP55 protection rating for electrical Control cabinet
- Remote start/stop control (<50 m)
- Excellent performance in high and low temperatures
- Unit dimensions (mm): 1947 L x 1152 W x 1609 H
